> M type Pump
Air Pump BMI100G30
- Air Delivery: 600 L/min
- Motor Power: 7.5 kw / 10 hp
- Max. pressure: 3 mpa/ 435 psi
- Pump Speed: 600 rpm
- Product description: Belt Drive Air Pump M Type Max Pressure: 3 mpa /435 psi Pulley: Φ510 mm/ 3B
Product introduction
|
Model |
BMI100G30 |
|
Air Delivery |
600 L/min |
|
Cylinder |
(Φ105x 100 mm)x 2 + (Φ63.5x 100 mm)x 1 |
|
Motor Power |
7.5 kw / 10 hp |
|
Pump Speed |
600 rpm |
|
Max Pressure |
3 mpa /435 psi |
|
Body Material |
Cast Iron |
| Pulley diameter | Φ510 mm/ 3B |
| Inlet unloader | without |
| Packing | 86x 54x 82.5 cm, plywood case |
| N.W. |
150 kg |
