> V type Pump - Heavy Duty
Air Pump BVI55L
- Air Delivery: 543 lit/min
- No. Of Cylinder: 2-single stage
- Motor Power: 5.5hp
- Engine Power: 9.0hp
- Product description: Belt drive air pump - V type - BVI55L Air delivery: 543 lit/min Pump speed: 900 rpm Max. pressure: 10bar/145psi Body material: cast iron
Product introduction
|
Model |
BVI55L |
|
Air delivery |
543 lit/min |
|
Cylinder |
(Φ80 x 60 mm) x 2 |
|
Motor power |
4.0 kw / 5.5 hp |
|
Engine power |
9.0 hp |
|
Pump speed |
950 rpm |
|
Max. pressure |
10 bar / 145 psi |
|
Body material |
cast iron |
|
Pulley diameter |
Φ360 mm/ 2A |
| Inlet unloader | without |
| Packing | carton |
|
N.W. |
29 kg |
