> H type Pump - Iron Case
Air Pump BHII30
- Air delivery: 237 lit/min
- Motor power: 3.0 hp
- Pump speed: 1,180 rpm
- Max. pressure: 10 bar /145 psi
- Product description: Belt drive air pump - H type - BHII30 Air delivery: 237 lit/min Motor power: .3.0 hp Pump speed: 1,180 rpm Max. pressure: 10 bar / 145 psi
Product introduction
| Model | BHII30 |
| Air delivery | 237 lit/min |
| Cylinder | (Φ65 x 50 mm) x 2 |
| Motor power | 2.2 kw / 3.0 hp |
| Engine power | 5.5 / 6.5 hp |
| Pump speed | 1,180 rpm |
| Max. pressure | 10 bar / 145 psi |
| Body material | cast iron |
| Pulley diameter | 320 mm |
| N.W. | 21.5 kg |
