> M type Pump
Air Pump BMII150G30A
- Air Delivery: 1,500 L/min
- Motor Power: 7.5 kw / 10 hp
- Max. pressure: 3 mpa/ 435 psi
- Pump Speed: 750 rpm
- Product description: Belt Drive Air Pump M Typel Max Pressure:3 mpa /435psi Pulley 350mm/4B plus 650mm fan
Product introduction
|
Model |
BMII150G30A |
|
Air Delivery |
1,500 L/min |
|
Cylinder |
(Φ125x 80 mm)x 2 + (Φ76x 80 mm)x 1 |
|
Motor Power |
10 kw / 15 hp |
|
Pump Speed |
750 rpm |
|
Max Pressure |
3 mpa/ 435 psi |
|
Body Material |
Cast Iron |
| Pulley diameter | Φ350 mm/ 4B + Φ650 mm fan |
| Inlet unloader | without |
| Packing | 86x 60x 80 cm, plywood case |
| N.W. |
175 kg |
